Product Details
- Size: 90cbm
- Place of Origin: jining
- Brand Name:
- Model Number: ZZ5315CCYM4663D1
- Weight: 31000.000 kg
| HOHAN 8×4 Flatbed Cargo TRUCK QUOTATION | |||||
| No. | Model | Driving type | Engine output | Dimension of the Van Body | Unit price FOB China Main Port USD |
| 1 | ZZ5315CCYM4663D1 | 8X4 | 300hp | 9600×2400×800(mm) | |
| MAIN SPECIFICATIONS | |||||
| Model | ZZ5315CCYM4663D1 | Steering | ZF8098 | ||
| Engine | Brand SINOTRUK | Gross Vehicle Weight | 31000kg | ||
| WD615.97E | Kerb Weight | 12200kg | |||
| Maximum Output | 300HP | Tyres | 11.00-20 | ||
| Rated engine power (KW/r/min) | 221/2200 | Wheelbase | 1800+4600+1350mm | ||
| Transmission | HW13710C(10forward,2reverse) | Loading Capacity | 19180kg | ||
| Front Axle | HF7 | ||||
| Max.loading:6500kg | |||||
| Rear Axle | HC16 Ratio:4.875 | Cargo type | Flatbed | ||
| Max.loading:17500kg | |||||
| Cab | H18(two bed) | Maximum Speed | 102 km/h | ||
| Air-condition | |||||
| Overall Dimension（ mm ） | 11995×2496×3980 | ||||
